USB-C Male-to-Male DC PD Emulator Trigger Cable for Laptop | Selected 5521 5525 Power Scope
-
Quotation & delivery: Include your required quantity, destination and timing in the enquiry. Confirm the selected build, lead time, shipping charges and any return terms in the agreed quotation before ordering.
-
End connectionUSB connection
-
Typedc cable
-
BrandReliaPackagingpe bag
-
DescriptionPD Emulator Trigger ChargeMfg. Date Code-
-
InstallationSurface MountOperating Temperature-
-
Connector TypeType CShieldingNo
-
Internal Switch(s)-Pins2 pins
-
Insulation ColorblackTerminals-
-
Actual Diameter-Signal Lines-
-
typeType c to dc 5521mm charging cablecable wire2464 28awg,24awg,20awg
-
JacketPVCvoltage5v 9V 12V 15V 20V
-
cable colorblacklength1m,1.2m,1.5m,1.8m,2m,3m
-
connectornickel ,goldfunctioncharging
-
Products StatusStock
This black PVC charging-cable request features a USB-C-to-DC male-to-male connection and PD emulator/trigger function. Laptop-adapter requirements include a featured 5.5 × 2.1 mm barrel interface, with the actual barrel version and complete power configuration to be agreed.
Choose the laptop barrel interface
Resolve the required 5521 versus 5525 connection with the receiving device socket. Confirm both end interfaces, polarity and pin assignment so the actual male-to-male arrangement is clear for the selected laptop power path.
Map the requested current and power
Agree which 5, 9, 12, 15 or 20 V profile the emulator/trigger arrangement must provide. Resolve the featured 5 A/100 W requirement within that actual configuration and obtain applicable support for the complete current/power scope.
Match the selected PD source and laptop input with the supplied profile. The voltage, current and power brief should describe one operating arrangement for the chosen cable.
Define wire and component construction
Select actual 2464 wire in 28, 24 or 20 AWG with PVC jacket and black cable/insulation finish. Identify where the two-pin and surface-mount requirements apply in the selected component or assembly arrangement.
Choose nickel or gold connector finish with the actual barrel and USB-C build. Keep those physical requirements associated with the selected electrical profile and receiving-device connection.
Set the supplied route
Reach requirements include 1, 1.2, 1.5, 1.8, 2 and 3 m. Agree the exact dimension for the source-to-laptop installation and complete the brief with barrel polarity, component/wire scope, trigger profile and correctly assigned current/power requirements.
Provide the product reference, selected configuration, quantity and destination. Confirm drawings, applicable ratings and acceptance requirements for the requested build. Lead time, shipping arrangements, charges and any return conditions should be reviewed in the agreed quotation before ordering.
