This molded Y-type AC splitter-cord enquiry features a NEMA 5-15P male supply connection and two NEMA 5-15R female outlets. The featured electrical request is 110 V and 10 A. The actual US option is 0.5 m, matching the described half-metre length.
Define the two-outlet layout and finished cable construction
SJT or SVT 18AWG/3C cable is described, with rubber or PVC jacket choices. Copper/PVC materials are listed alongside copper, CCA or CCS conductor alternatives. Confirm the chosen wire type, conductor material, strand dimensions and jacket material for the complete Y assembly. Specify the main lead, each branch length, connector orientation and molded junction dimensions in the drawing.
- The featured connection is NEMA 5-15P to two 5-15R outlets.
- A molded Y configuration is requested.
- The cable description is 18AWG with three cores.
- The selected catalogue length is 0.5 m.
- IP11 is the stated enclosure reference.
Set the complete assembly rating and combined branch demand
The broader current field lists 10, 13 or 15 A. Select the applicable complete-cord rating for the featured 110 V/10 A request. Give both appliance loads and their combined demand, together with the supply and receiving interfaces. Keep outlet ratings, branch conductors and junction construction in the same review; two outlets do not establish twice the selected assembly capacity.
Use one reviewed specification for samples and production
OEM/ODM supply, two or three free sample pieces and a two-year warranty are stated. Request applicable RoHS, CE and specific selected-cord approval evidence for the listed USA reference. Include actual routing, exposure, quantity and agreed warranty scope with the same conductor/jacket and Y-branch drawing used for sample evaluation.
